Description
Key Features
- 3 Ton Load Capacity – Heavy-duty performance for demanding applications.
- Manual Hydraulic Lift System – Smooth and controlled lifting operation.
- Equipped with Hand Brake – For slope safety and load control.
- Lightweight Alloy Steel Frame – Strong yet easy to manoeuvre.
- PU Wheels – Low noise, wear-resistant, and floor-friendly.
- Compact Turning Radius – Designed for tight spaces and aisles.
- Low Maintenance – Reliable AC hydraulic pump system.
Technical Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Model No. | MAXX–MRHP–3.0 Ton | Product Type | Manual Hand Pallet Truck |
| Load Capacity | 3000 Kg | Operation Type | Hydraulic with Hand Brake |
| Maximum Platform Height | 160 mm | Maximum Working Height | 850 mm |
| Fork Height (Max/Min) | 205 mm / 85 mm | Fork Length | 1150 mm |
| Fork Overall Width | 540 mm | Single Fork Width | 160 mm |
| Front Wheel Size | Ø80 × 60 mm | Rear Wheel Size | Ø200 × 50 mm |
| Wheel Material | Polyurethane (PU) | Net Weight | 70 Kg |
| Pump Type | AC Hydraulic Pump | Frame Material | Alloy Steel |
| Surface Finish | Powder Coated | Colour Option | Red / Yellow |
Applications
- Warehouses and distribution centres
- Industrial production plants
- Packaging and shipping areas
- Construction material handling
- Loading/unloading docks
Maintenance & Service
- Regularly check hydraulic oil and handle linkage.
- Lubricate wheel bearings and axles monthly.
- Store in a dry, dust-free environment.
- MAXXLIFT service centres: Sonipat, Gurugram, Kundli, Bhiwadi.
Warranty
• 1-Year Warranty on hydraulic and frame components.
• Lifetime after-sales support and spare parts availability from MAXXLIFT Motors Pvt. Ltd.
