Description
Applications
- Warehouses and manufacturing plants
- Machine maintenance and assembly areas
- Construction and building interiors
- Industrial workshops and logistics hubs
- Narrow or restricted workspaces where forklifts cannot enter
Features
- Fully electric operation for lifting and movement
- Adjustable telescopic boom with wide lifting angles
- Foldable outriggers for compact storage and easy transport
- Ideal replacement for forklifts in tight areas
- Smooth, precise lifting and easy manoeuvrability
- Long boom reach for extended working range
- Low maintenance with energy-efficient electric system
Description
The MAXXLIFT Fully Electric Single Arm Crane combines mobility, power, and precision.
Its strong single-arm telescopic boom offers multiple reach and angle options, enabling lifting of loads up to 1000 kg.
The crane operates fully on electric power — no manual pumping required — offering smooth hydraulic lifting and controlled movement.
Foldable support legs reduce storage space, while heavy-duty wheels ensure stable movement on any floor type.
Built with a robust steel frame and premium electrical components, it’s the perfect solution for safe and efficient lifting in industrial environments.
Its strong single-arm telescopic boom offers multiple reach and angle options, enabling lifting of loads up to 1000 kg.
The crane operates fully on electric power — no manual pumping required — offering smooth hydraulic lifting and controlled movement.
Foldable support legs reduce storage space, while heavy-duty wheels ensure stable movement on any floor type.
Built with a robust steel frame and premium electrical components, it’s the perfect solution for safe and efficient lifting in industrial environments.
Technical Specifications
| Parameter | Detail | Parameter | Detail |
|---|---|---|---|
| Model No. | MAXXLIFT – Fully Electric Single Arm Crane | Operation Type | Fully Electric |
| Power Source | Electric Motor | Structure | Single Arm Telescopic Boom |
| Maximum Rated Load | 1000 kg | Net Weight | 466 kg |
| Outrigger Inner Width | 985 mm | Outrigger Outer Width | 1170 mm |
| Front Wheel Size | Ø 150 × 50 mm | Training Wheel Size | Ø 75 × 30 mm |
| Boom Type | Adjustable Telescopic | Lifting Control | Electric Hydraulic |
Load Capacity Table by Boom Angle
| Boom Angle | Boom Length (mm) | Rated Load (kg) |
|---|---|---|
| 0° | 440 / 2300 / 2500 / 2700 / 2900 / 3100 | 1000 / 342 / 290 / 250 / 220 / 200 |
| 40° | 985 / 1610 / 1756 / 1900 / 2045 / 2090 | 1000 / 565 / 430 / 345 / 290 / 250 |
Key Advantages
- 100% electric lifting and travel control
- Compact design ideal for limited workspaces
- Wide range of lifting angles and telescopic boom
- Strong structural stability with safe hydraulic performance
- Quiet, efficient, and eco-friendly electric drive system
- Foldable outriggers for quick deployment and mobility
- Long service life and low maintenance cost
Services and Support
- MAXXLIFT provides installation, product training, and maintenance services.
- Service and spare part support available at Sonipat, Gurugram, Kundli, and Bhiwadi branches.
- On-site service within 24–48 hours for quick assistance.
Warranty
12-month standard warranty from date of delivery covering electrical and hydraulic systems.
Extended warranty and AMC available on request.
Delivery
Standard delivery within 2–3 weeks after order confirmation and advance payment.
Immediate dispatch available for ready-stock models.
Delivery Locations: PAN India including Delhi NCR, Haryana, Punjab, Rajasthan, Uttar Pradesh, Gujarat, Maharashtra, and major industrial zones.
Why Choose MAXXLIFT
- Precision-engineered Indian manufacturing
- Compact, safe, and energy-efficient design
- Fully electric lifting and driving system
- Durable construction with minimal maintenance
- Reliable after-sales and service support across India
